G0932 - Harvey 69.57 x 1.78 Meter Base O-Rings (Pack of 2) | Genuine Seals for H2O & H25 Meter Assemblies

The Harvey G0932 Meter Base O-Rings are the primary seals required to create a watertight interface between the meter assembly and the softener manifold. This pack contains two high-quality, genuine replacement O-rings designed specifically for the rigorous pressure cycles of Harvey twin tank systems.

⚠️ Compatibility

• Supported Models: Fits Harvey H2O and H25 series twin tank water softeners.

• Essential For: Both the G3258 Service Meter and the G2345 Regeneration Meter.

• Note: Not suitable for newer H20b or H20c models.

Key Symptoms: Why Replace the G0932 O-Rings?

O-rings are wear-and-tear components that perish over time due to compression and mineral contact. You should replace these if you notice:

• Seepage at the Meter Base: Water weeping from the point where the meter assembly meets the main softener body.

• Salt Bridging/Crusting: White, salty deposits forming around the base of the meters, indicating a slow, pressurized leak.

• Loss of Suction: If air is being drawn in through a perished O-ring during the regeneration cycle, it can prevent the brine from being pulled into the system.

• Routine Maintenance: We strongly recommend replacing the G0932 O-rings every time a meter is removed or replaced to ensure a fresh, reliable seal.

Features & Benefits

• Genuine Harvey Spares: Manufactured from high-grade EPDM rubber for superior chemical resistance and longevity.

• Perfect Compression Fit: Engineered to the exact cross-section diameter required for a leak-free seal under standard mains pressure.

• Cost-Effective Prevention: Replacing these inexpensive seals during a service prevents future water damage to the cabinet and internal components.

• Easy Installation: Simply lubricate with food-grade silicone grease and seat into the meter base grooves.
