14 - 1000215 FOR 14in Diameter Vessels 4.8gpm, 18.2lpm Backwash Flow Controller for Autotrol Valves (No Ball Required)

The 1000215 is a fixed-orifice backwash flow controller sized for 14in diameter resin vessels, rated at 4.8gpm (18.2lpm), fitting into the drain line flow control (DLFC) housing on Autotrol control valves without a separate ball. It sets the backwash flow rate so the resin bed lifts, expands and cleans properly without resin being carried away to drain. It's the part to fit when rebuilding a 14in vessel or replacing a worn or missing controller from WrekinWater.

Technical specifications

Symptoms that mean you need this part

• Resin or filter media visible in the drain water during backwash
• Weak or short backwash that doesn't seem to lift or clean the bed properly
• Softening or filtration performance dropping off between services despite salt or media being topped up correctly
• Old controller washer cracked, deformed or missing from the DLFC housing

Why it fails / why it matters

Backwash flow has to be tuned to the vessel diameter so the bed expands by the right percentage, loosening compacted media and flushing out sediment and iron fouling without lifting resin high enough to escape to drain. A worn, wrong-sized or missing flow controller either starves the backwash of flow, leaving the bed dirty and prone to channelling, or lets too much water through and strips resin out of the vessel over successive regenerations.

Why buy this from WrekinWater

WrekinWater holds the complete Autotrol flow controller range by vessel size alongside Pentair Fleck, Clack and Kinetico spares, built on more than 15 years trading from Bettisfield, Shropshire (UK Company No. 11000488) and over 50,000 customers served. Stock is dispatched quickly and the business carries an Excellent Trustpilot rating, useful when a vessel rebuild is waiting on the correct part.

How to fit it

1. Isolate the softener at the bypass and shut off the mains supply
2. Locate the drain line flow control (DLFC) housing on the control valve body
3. Release the retaining cap or clip and lift out the old flow controller washer
4. Fit the new 1000215 controller, checking the o-ring is present and undamaged
5. Refit the DLFC cap securely and restore the mains supply
6. Run a manual regeneration and check the backwash flow rate at the drain matches expectations
