T245250 Open End Quartz Sleeve for models PC-1 - QJ24250

This open-ended quartz sleeve, part number QJ24250 and also listed as T245250, is the correct replacement for Wonder UV PC-1 disinfection systems. It fits over the UV lamp inside the PC-1 housing, keeping the lamp dry while letting UV-C light pass through to treat the water flowing past it. Fit a new sleeve when the existing one has scaled, clouded or is due its annual replacement.

Signs your quartz sleeve needs replacing

• Cloudiness, limescale or scratching visible on the glass
• A yellow or brown tint developing on the sleeve
• Water starting to taste or smell slightly off
• The sleeve has been fitted for around a year

In the Wonder UV PC-1, the quartz sleeve keeps the UV lamp completely dry while still letting UV-C light shine through the glass to disinfect the water passing around it. Scale, staining or fine scratches that build up on the sleeve over time cut down how much UV light actually reaches the water, so the system can under-perform even while the lamp is still working. A new QJ24250 sleeve restores full transmittance.

WrekinWater is a family run business based in Bettisfield, Shropshire, rated Excellent on Trustpilot, with 15 years' experience supplying water treatment parts to more than 50,000 customers. This sleeve is made to the PC-1's specific dimensions, so it fits as a genuine like-for-like replacement.

How to replace it

1. Isolate the water supply to the PC-1 unit and drain the housing
2. Undo the retaining nut or union to access the lamp chamber
3. Withdraw the lamp, then slide out the old open-ended sleeve
4. Clean the housing and fit new O-rings
5. Fit the new QJ24250 sleeve and reinsert the lamp
6. Restore water and power, then run to drain briefly before use
