10 - 1000212 - for 10in Diameter vessel 2.5gpm, 9.5lpm Backwash Flow Controller for Autotrol Valves (No Ball Included)

The Autotrol 1000212 is the genuine drain line flow control (DLFC) button sized for a 10-inch diameter resin vessel, rated at 2.5gpm / 9.5lpm. It regulates backwash flow so the resin bed fluidises correctly without washing resin down the drain — the fix behind searches for "resin in drain water", "Autotrol backwash flow control" or "DLFC replacement". Genuine Pentair Autotrol part, in stock at WrekinWater.

Technical specifications

Symptoms that mean you need this part

• Resin beads appearing in the drain water, or turning up downstream in taps or appliances — a sign the backwash flow is too high for a missing or worn DLFC
• Weak or ineffective backwashing where the resin bed doesn't visibly lift, leaving it compacted so water channels through instead of contacting the full bed
• Hardness breakthrough earlier than expected, because a compacted, channelled bed can't do its job properly even though everything else is working

Why it fails / why it matters

Backwash flow has to be matched to the diameter of your resin vessel: a wider tank has a wider (and heavier) resin bed, so it needs proportionally more flow to lift and fluidise it, while a narrower tank needs less or it will simply wash resin away. This part is specifically sized for a 10-inch diameter vessel — fitting the wrong size, or running without one at all if it's gone missing, either starves the backwash or overdoes it.

Why buy this from WrekinWater

Getting the DLFC size wrong is an easy mistake with real consequences — resin loss down the drain isn't cheap to put right. WrekinWater stocks the full range of vessel-diameter sizes and checks yours against your tank before dispatch. 15 years' experience, rated Excellent on Trustpilot, UK stock.

How to fit it

1. Bypass the valve and relieve pressure.
2. Remove the drain line fitting at the base of the valve to access the flow control button.
3. Unscrew the old button and fit the new one, double-checking the size stamped on it matches your vessel diameter before refitting.
4. Reassemble the drain fitting and restore water.
5. Run a manual backwash and visually check the drain water for resin loss — you shouldn't see any beads once the correct-sized controller is fitted.
