PPG 40" Spectrum Premier Pleat Glass Fibre PPG
PPG 40" Spectrum Premier Pleat Glass Fibre PPG
SKU:PPG-0.45-40-Single
Share
Product Description
Product Description
The 40" Premier Pleat PPG Glass Fibre Cartridge is the ultimate high-capacity solution for absolute rated particle removal. Engineered with hydrophilic Borosilicate glass fibre media, this cartridge delivers 99.98% to 99.9996% efficiency, meeting the rigorous demands of potable water filtration, cyst reduction, and beverage clarification applications.
Certified to NSF/ANSI Standard 53, the 40" PPG cartridge is optimised for Cryptosporidium and Giardia cyst removal, ensuring reliable filtration performance. With an expansive 1.64m² filtration surface area, this cartridge offers superior dirt-holding capacity, reduced maintenance, and high flow rates with minimal pressure drops, making it ideal for high-demand filtration systems.
Key Features & Benefits:
- Absolute Rated Filtration: Removes particles and microorganisms with up to 99.9996% efficiency.
- NSF-Certified Cyst Removal: Meets NSF/ANSI Standard 53, ensuring effective removal of Cryptosporidium and Giardia cysts.
- High Flow Rates: Hydrophilic Borosilicate glass fibre media supports high flow with low-pressure loss.
- Large Filtration Surface Area: 1.64m² maximises dirt-holding capacity and service life.
- Robust Construction: Polypropylene cage and thermally welded end caps ensure durability under demanding conditions.
- Certified and Tested: FDA-compliant, WRAS-approved materials ensure consistent, reliable performance.
- Hygienic Packaging: Double vacuum-sealed and individually boxed for contamination-free installation.
Applications & Industries:
The 40" Premier Pleat PPG Glass Fibre Cartridge is ideal for large-scale, high-demand filtration applications, including:
- Potable Water Filtration: Eliminates harmful cysts and microorganisms for safe water consumption.
- Cyst Reduction: Certified to remove Cryptosporidium and Giardia cysts with precision.
- Beverage Clarification: Ensures safety and clarity in high-volume production environments.
- Industrial Air and Gas Filtration: Delivers reliable, high-capacity particulate removal for critical systems.
Technical Specifications:
| Specification | Details |
|---|---|
| Materials | Borosilicate glass fibre media, polypropylene support layers, core, and end caps. |
| Surface Area (40") | 1.64m² |
| Operating Pressure | Maximum 6 bar at 21°C. |
| Maximum Temperature | 82°C (up to 120°C for sterilisation). |
| Sterilisation Cycles | 5 cycles of 20 minutes at 120°C. |
| Micron Ratings | 0.45, 1, 3, 5, 10 µm. |
| Length | 40". |
| Certifications | FDA compliant, WRAS approved, NSF/ANSI Standard 53. |
Ordering Guide:
Customise the 40" Premier Pleat PPG Cartridge to meet your specific filtration requirements:
- Micron Ratings: 0.45 to 10 µm.
- End-Caps & Seals: Options include PSU ring insert (Z) or stainless steel insert (Q).
Example: PPG-0.45-40EHS
Why Choose the 40" Premier Pleat PPG Cartridge?
The 40-inch Premier Pleat PPG Cartridge delivers unparalleled filtration performance with its advanced Borosilicate glass fibre media, large surface area, and absolute rated efficiency. Designed for high-capacity systems, it ensures reliable performance for potable water filtration, beverage production, and cyst reduction, all while minimising maintenance and operating costs.
