Disc 7 - Kinetico Meter Disc - Up to max hardness of 419ppm (mg/) 1510

The Kinetico Meter Disc 7 (p/n 1510) is the calibration disc fitted inside the meter cap of Kinetico non-electric water softeners, matching your softener's regeneration timing to a water hardness of up to 419ppm (mg/l). WrekinWater supplies genuine Kinetico meter discs to households on very hard water supplies who need their softener recalibrated to a confirmed hardness test result, so it regenerates at exactly the right point rather than too early or too late.

Technical specifications

Symptoms that mean you need this part

• A recent water hardness test shows a reading close to or above your current disc's rating
• Softened water is starting to feel or test hard before the next regeneration is due
• You've moved into a new property and haven't confirmed the meter disc matches your local hardness
• Your water supplier or a home hardness test kit indicates very hard water in the 400+ ppm range

Why it fails / why it matters

Kinetico non-electric softeners use a flow meter fitted with a calibrated disc to count exactly how much water has passed through before triggering a regeneration. The disc rating has to match the hardness of your incoming water — too high a rating for your actual hardness lets treated water run past its true capacity and hardness breaks through, while too low a rating triggers wasteful, unnecessarily frequent regenerations. Disc 7 is sized for supplies tested up to 419ppm, so it needs to be matched against a current hardness test rather than swapped on assumption.

Why buy this from WrekinWater

WrekinWater has served more than 50,000 customers over 15 years from our base in Bettisfield, Shropshire, and stocks genuine Kinetico parts alongside Pentair Fleck, Autotrol and Clack components, so you can order the exact disc your hardness test calls for with confidence. As a UK company (Company No. 11000488) rated Excellent on Trustpilot, we back every order with straightforward advice if you're not sure which disc your meter needs.

How to fit it

1. Confirm your current water hardness in ppm (mg/l) using a test kit or your water supplier's data before ordering
2. Turn the softener to bypass and relieve pressure in the system
3. Locate and remove the meter cap on the Kinetico control valve
4. Lift out the existing calibration disc and note its orientation
5. Fit the new Disc 7 in the same orientation and refit the meter cap securely
6. Return the softener to service and monitor softened water quality over the following days
