PPG 20" Spectrum Premier Pleat Glass Fibre
PPG 20" Spectrum Premier Pleat Glass Fibre
SKU:PPG-0.45-20-Single
Share
The 20" Premier Pleat PPG Glass Fibre Cartridge is a high-capacity filtration solution designed for absolute rated particle removal with exceptional flow rates. Its hydrophilic Borosilicate glass fibre media, combined with two rigid support layers, ensures durability and efficiency while maintaining 99.98% to 99.9996% filtration efficiency.
Certified to NSF/ANSI Standard 53, this cartridge is optimised for Cryptosporidium and Giardia cyst removal, making it a reliable choice for potable water systems, beverage production, and cyst reduction. With a 0.82m² filtration surface area, the 20" PPG cartridge delivers excellent dirt-holding capacity and minimal pressure drops, ensuring long service life and optimal performance.
Key Features & Benefits:
- Absolute Rated Filtration: Achieves up to 99.9996% efficiency for reliable removal of particles and micro-organisms.
- Certified Cyst Removal: Meets NSF/ANSI Standard 53 for removing Cryptosporidium and Giardia cysts.
- High Flow Rates: Hydrophilic Borosilicate media supports superior flow with minimal pressure loss.
- Large Filtration Surface Area: 0.82m² enables extended service life and reduced maintenance.
- Robust Design: Polypropylene cage and thermally welded end caps protect the pleat pack for durability under demanding conditions.
- Certified Safety: FDA-compliant, WRAS-approved, and laboratory-grade materials ensure consistent and safe operation.
- Hygienic Packaging: Double-layer vacuum-sealed and individually boxed for assured cleanliness and contamination prevention.
Applications & Industries:
The 20" Premier Pleat PPG Glass Fibre Cartridge is ideal for high-demand filtration in:
- Potable Water Filtration: Removes harmful cysts and micro-organisms to ensure water safety.
- Cyst Reduction: Certified to remove Cryptosporidium and Giardia with precision.
- Beverage Clarification: Ensures clarity and safety for high-volume beverage production.
- Industrial Air and Gas Filtration: Reliable filtration for precise particulate removal in demanding systems.
Technical Specifications:
| Specification | Details |
|---|---|
| Materials | Borosilicate glass fibre media, polypropylene support layers, core, and end caps. |
| Surface Area (20") | 0.82m² |
| Operating Pressure | Maximum 6 bar at 21°C. |
| Maximum Temperature | 82°C (up to 120°C for sterilisation). |
| Sterilisation Cycles | 5 cycles of 20 minutes at 120°C. |
| Micron Ratings | 0.45, 1, 3, 5, 10 µm. |
| Length | 20". |
| Certifications | FDA compliant, WRAS approved, NSF/ANSI Standard 53. |
Ordering Guide:
Configure the 20" Premier Pleat PPG Cartridge to meet your filtration needs:
- Micron Ratings: 0.45 to 10 µm.
- End-Caps & Seals: Options include PSU ring insert (Z) or stainless steel insert (Q).
Example: PPG-0.45-20EHS
Why Choose the 20" Premier Pleat PPG Cartridge?
The 20-inch Premier Pleat PPG Cartridge is built for efficiency and reliability, offering advanced filtration performance for high-demand applications. With its large filtration surface area, certified safety standards, and durable construction, it is the ideal solution for potable water systems, beverage production, and industrial filtration needs.
